Now, it is completed in a fraction of the time with only basic training (and certification to operate UAVs) needed. Previously, it took expensive equipment operated by highly-trained technical staff to get basic Reality Capture data of a site. Measure and edit point clouds in Autodesk ReCap software. This makes it easier to detect issues earlier than with traditional surveying methods and give a close-up view of issues that might cause rework, such as structural bowing, thermal changes, incorrect installation of MEP systems, and more.Įven better, once scan data is aligned to a 3D model, architects and engineers gain a clear understanding of site restrictions and challenges and can overcome them through creative design – taking care of problems much earlier in the design process. Designers benefit from the confidence that their base information is a model of up-to-date data of actual site conditions. The final product is a point cloud created in a matter of minutes that can be imported into CAD and BIM tools. Here reality capture software, like Autodesk ReCap steps in and data captured by the hardware automatically registered, stitched into a coordinate system, cleaned up, and analyzed. Once a site is scanned, a detailed set of data or “points” is captured for further processing. Reality capture is the process of producing a digital 3D model representation of your object, building, or site by scanning it in the field using hardware such as laser scanners or camera-mounted UAVs. The output is a highly-accurate, actionable set of real-time data, which can be directly connected into 2D and 3D design processes. Reality capture helps teams reduce errors, minimize labor requirements, save time, and reduce risk. Verifying and updating these manually is a lot of leg work.ĭigital reality capture is changing this. You’re almost guaranteed to start a project using static 2D image documentation of existing conditions.
Renovations projects are a particular challenge since the infrastructure or building may be decades old and designed before the age of digital blueprints. As any surveyor or field engineer knows, capturing existing field conditions for an infrastructure project or building renovation is a tedious, manual, often analog, and inaccurate process – not to mention dangerous.
